320W 36V Polycrystalline Silicon Solar Panels / Multicrystalline Silicon Solar Cells

320W 36V Polycrystalline Silicon Solar Panels / Multicrystalline Silicon Solar Cells

    • 320W 36V Polycrystalline Silicon Solar Panels / Multicrystalline Silicon Solar Cells
    • 320W 36V Polycrystalline Silicon Solar Panels / Multicrystalline Silicon Solar Cells
    • 320W 36V Polycrystalline Silicon Solar Panels / Multicrystalline Silicon Solar Cells
    • 320W 36V Polycrystalline Silicon Solar Panels / Multicrystalline Silicon Solar Cells
  • 320W 36V Polycrystalline Silicon Solar Panels / Multicrystalline Silicon Solar Cells

    Product Details:

    Place of Origin: China
    Brand Name: URILIC
    Certification: CQC, TUV, CE, ROHS
    Model Number: 310W, 315W, 320W

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Plywood box
    Delivery Time: 5-15 days
    Payment Terms: T/T
    Supply Ability: 1000PCS/week
    Contact Now
    Detailed Product Description
    Name: Polycrystalline Solar Panel Power: 310W, 315W, 320W
    Size: 1956*992*40mm Weight: 22.5kg
    Solar Cell: Poly 156*156 Cell Number Of Cells: 72pcs
    Max. Overcurrent: 15A Application Class: Class A
    High Light:

    polycrystalline silicon solar panels

    ,

    mono versus poly solar panels

    310W-320W-36V Polycrystalline Solar Panel Polycrystalline Silicon Solar Panel

    Description:

    Polycrystalline solar panels are made from similar silicon material hence instead of going through the slow and more expensive process of creating a single crystal, molten silicon is just put into a cast and cooled with a seed crystal.

    By using the casting method, the crystal surrounding the seed isn’t uniform and branches into many, smaller crystals, thus the term “polycrystalline”. The surface has a jumbled look with many variations of blue colour. We has developed various types of polycrystalline solar modules.

    Polycrystalline solar panels generally have lower efficiencies than monocrystalline options, but their advantage is a lower price point. In addition, polycrystalline solar panels tend to have a blue hue instead of the black hue of monocrystalline panels.

    Product Features:

    1. High module conversion efficiency up to 17% through advanced manufacturing technology.
    2. Low degradation and excellent performance under high temperature and low light conditions.
    3. Robust aluminum frame ensures the modules to withstand wind loads up to 2400Pa and snow loads up to 5400Pa.
    4. Positive power tolerance of 0 ~ + 3 %.
    5. High ammonia and salt mist resistance.
    6. Efficient protection from frame deformation and water accumulation.
    7. Rugged design to withstand high wind pressure and snow load, easy installation.


    Product Details:

    ModelU310P-24U315P-24U320P-24
    Peak Power (W)310±3%315±3%320±3%
    Open circuit voltage (V)45.345.545.5
    Peak Voltage (V)36.537.037.0
    peak current (A)8.488.518.64
    Short-circuit current (A)9.099.119.25
    Cell efficiency17.8%18.1%18.3%
    Component Efficiency15.97%16.25%16.5%
    Maximum overcurrent (A)15A
    Maximum system voltage (V)1000V DC
    Rated operating temperature48±2°C
    Working temperature range-40°C- +85°C
    Current temperature coefficient0.1%/°C
    Voltage temperature coefficient-0.37%/°C
    Power Temperature Coefficient0.45%/°C
    Solar Cell156*156*0.19mm
    Number of cells72 pcs
    Size1956*992*40mm
    Weight22.5 kgs
    Surface PackagingLow iron tempered glass/3.2mm
    SealantEthylene Vinyl Acetate (EVA)
    BorderAnodized Aluminum/Silver
    Junction Box Waterproof Level≥IP65
    Pre-wind pressure5400Pa
    Back wind pressure2400Pa
    Maximum hail impact25mm/ 23m/s


    Mechanical drawing:
    320W 36V Polycrystalline Silicon Solar Panels / Multicrystalline Silicon Solar Cells



    Our advantage:

    1. High quality products and affordable prices.
    2. Energy saving, environmental-friendly, Safty, No pollution.
    3. Advanced technology, strict quality control system.
    4. Easy installation, safe operation, free maintenance.
    5. 10-year product warranty,12-year warranty at 90% power output,25-year warranty at 80% power output.
    6. Quality in priority, clients the upmost.
    320W 36V Polycrystalline Silicon Solar Panels / Multicrystalline Silicon Solar Cells



    Solar Panel Application:

    320W 36V Polycrystalline Silicon Solar Panels / Multicrystalline Silicon Solar Cells
