| Place of Origin: | China |
| Brand Name: | URILIC |
| Certification: | UL |
| Model Number: | 5W,6W |
| Minimum Order Quantity: | 100pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood box |
| Delivery Time: | 5-15 days |
| Payment Terms: | T/T |
| Supply Ability: | 1000PCS/week |
| Product Name: | Monocrystalline Solar Module | Power: | 5W,6W |
|---|---|---|---|
| Size: | 285*185*18mm | Weight: | 1kg |
| Max. System Voltage: | 1000V DC | Module Class: | Class A |
| Frame: | Anodized Aluminium Alloy Or Frameless As Request | Application: | Solar System LED Low Power System |
| High Light: | monocrystalline silicon pv panels,mono silicon solar panels |
||
6W Monocrystalline Silicon Cells 18V Small Monocrystalline Pv Cell 5W Solar Panel
Description:
Small solar panels can be applied to portable solar power, solar garden lights, solar traffic lights, small wind and solar hybrid power generation systems and other application scenarios. Monocrystalline Solar Panels have been the go-to the choice for many years. They are among the oldest, most efficient and most dependable ways to produce electricity from the sun. Each module is made from a single silicon crystal and it is recognized by their colour, which is typically black or iridescent blue.
Features:
Product Details:
| Model | U-5M-12 | U-6M-12 | ||
| Peak Power (W) | 5±3% | 6±3% | ||
| Open circuit voltage (V) | 21.6 | 21.6 | ||
| Peak Voltage (V) | 18.0 | 18.0 | ||
| peak current (A) | 0.28 | 0.33 | ||
| Short-circuit current (A) | 0.31 | 0.36 | ||
| Cell efficiency | 18.0% | 21.0% | ||
| Maximum system voltage (V) | 1000V DC | |||
| Rated operating temperature | 48±2°C | |||
| Working temperature range | -40°C- +85°C | |||
| Current temperature coefficient | 0.1%/°C | |||
| Voltage temperature coefficient | -0.37%/°C | |||
| Power Temperature Coefficient | 0.45%/°C | |||
| Solar Cell | Single crystal silicon cell | |||
| Size | 285*185*18mm | |||
| Weight | 0.6 kgs | |||
| Surface Packaging | Low iron tempered glass/3.2mm | |||
| Sealant | Ethylene Vinyl Acetate (EVA) | |||
| Border | Anodized Aluminum/Silver | |||
| Junction Box Waterproof Level | ≥IP65 | |||
| Pre-wind pressure | 5400Pa | |||
| Back wind pressure | 2400Pa | |||
| Maximum hail impact | 25mm/ 23m/s | |||
5W-6W-18V small solar panel assembly size chart
Our advantage:
|
|
||
Solar CellHigh Efficiency PV Cells |
FrameFrame thinkness>18mm Oxidation Film>15Pm TUV&UL standard sillica gel Ability to resist 5400Pa mechanical pressure Good anti-corruption performance in seaside environment
|
Solar junction boxPPO material, IP67. Heat dissipation Long service life |
