Energy Saving High Luminous Led Street Light Fixture 120w High Efficiency ZAG Lens

Energy Saving High Luminous Led Street Light Fixture 120w High Efficiency ZAG Lens

    • Energy Saving High Luminous Led Street Light Fixture 120w High Efficiency ZAG Lens
    • Energy Saving High Luminous Led Street Light Fixture 120w High Efficiency ZAG Lens
    • Energy Saving High Luminous Led Street Light Fixture 120w High Efficiency ZAG Lens
    • Energy Saving High Luminous Led Street Light Fixture 120w High Efficiency ZAG Lens
  • Energy Saving High Luminous Led Street Light Fixture 120w High Efficiency ZAG Lens

    Product Details:

    Place of Origin: SHENZHEN
    Brand Name: URILIC
    Certification: ETL, DLC, ENEC, TUV, CE
    Model Number: LED Street Light 90W 120W 150W

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Carton box
    Delivery Time: 5-15 days
    Payment Terms: T/T
    Supply Ability: 1000PCS/week
    Contact Now
    Detailed Product Description
    Product Name: LED Street Light Power: 90W, 120W, 150W
    LEDs Qty.: 90pcs Input Voltage: AC 185-265V
    Size: 612x336x91 Mm Packing Size: 662x395x150 Mm
    Gross Weight: 6.15 Kg Body Material: Aluminum 6063-T5
    High Light:

    high lumen led street light

    ,

    led street light bulb

    120w LED Street Light High Luminous Led Street Lights for Road Lighting



    Description:

    LED street light is made of heavy-duty die-cast aluminum with integrated radiator and tempered glass lens. It is made of high-quality materials. The LED street lamp is manufactured in strict accordance with high standards to ensure safe and reliable use.​ Designed by a professional industrial design team, it can be applied to wind and solar hybrid street lighting systems with high-end, stylish and atmospheric appearance. Automatically judge the weather and reasonably plan the discharge power.



    Quick Detail:

    1. Using high-efficiency ZAG lens technology, compared with similar products, the light efficiency is increased by 8% and the light transmittance is as high as 98%.
    2. With air duct heat dissipation design, the overall weight of the product is reduced and the heat dissipation performance is good, reducing light decay and prolonging the life of the light source. The mainstream CHEM modular design reduces maintenance costs for later use.
    3. Low energy consumption, constant current drive, energy saving 60%; overcurrent, overvoltage, lightning, high temperature protection to fully guarantee the product's life and stability.
    4. Rugged and long-lasting, up to 50,000 hours; no need to change fixtures frequently, no routine maintenance required.
    5. Green and environmentally friendly, the light source is free of ultraviolet rays, infrared radiation, and no mercury pollution.
    6. Beautiful appearance without dust, protection class IP66.
    7. Fast response, no stroboscopic; wide operating voltage range.
    8. The lamp bead is housed in two 1W dual crystal packages and the dead light rate is reduced by an order of magnitude.

    Mechanical Drawing:

    Energy Saving High Luminous Led Street Light Fixture 120w High Efficiency ZAG Lens



    Product Details:

    Model U-L1303-90 U-L1303-120 U-L1303-150
    Power 90W 120W 150W
    Light Effects 131 Lm/W 126 Lm/W 121 Lm/W
    Total luminous flux 117901 lm 151201 lm 181501 lm
    Color temperature 5000-5500K
    Color Rendering Index ≥70
    Light source brand Bridgelux
    Number of light sources 90pcs
    Lighting angle 150*45°/150*65°/150*70°
    Protection level IP66
    Working voltage 185-265V
    Working environment temperature -40°C~50°C, 20%~90% H.R
    Storage temperature -40°C~85°C, 10%~90% H.R.
    Power Efficiency 93%
    Power factor >0.95
    Lighting life >50000H
    Light pole size Φ60mm
    Light body material AL6063-T5
    Lighting size 612*336*91 mm (±5mm)
    Package size 662*395*150 mm (±5mm)
    Light weight of the fixture 6.15kg (±0.1kg)



    Distribution Curve:

    Energy Saving High Luminous Led Street Light Fixture 120w High Efficiency ZAG Lens



    Installation Diagram:

    Energy Saving High Luminous Led Street Light Fixture 120w High Efficiency ZAG Lens

    1. Open the back board and back cover;
    2. Connect the light wires and grid wires;
    3. Insert the lamp pole into the light, lamp pole dia φ60mm;
    4. Make sure the light is steady, lock the push board M10 Hexagon socket head cap screws, fix the light tightly onto the pole arm;
    5. Close the back board, then back cover. Done;
    6. Connect light power supply wire and grid wire according to above picture, blue to N, brown to L, yellow&green to E.



    Applications:

    LED Street Light is widely used in urban expressways, highways, trunk roads, secondary roads, access roads, streets, factories, schools, gardens, parks, community, garden plaza and other street lighting.
