IP66 120 Watt Led Street Light Fittings , High Power Led Lamp U-SL1302-120W

IP66 120 Watt Led Street Light Fittings , High Power Led Lamp U-SL1302-120W

    • IP66 120 Watt Led Street Light Fittings , High Power Led Lamp U-SL1302-120W
    • IP66 120 Watt Led Street Light Fittings , High Power Led Lamp U-SL1302-120W
    • IP66 120 Watt Led Street Light Fittings , High Power Led Lamp U-SL1302-120W
    • IP66 120 Watt Led Street Light Fittings , High Power Led Lamp U-SL1302-120W
  • IP66 120 Watt Led Street Light Fittings , High Power Led Lamp U-SL1302-120W

    Product Details:

    Place of Origin: SHENZHEN
    Brand Name: URILIC
    Certification: ETL, DLC, ENEC, TUV, CE
    Model Number: U-SL1302-120W

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiation
    Price: Negotiation
    Packaging Details: Carton box
    Delivery Time: 5-15 days
    Payment Terms: T/T
    Supply Ability: 1000PCS/week
    Contact Now
    Detailed Product Description
    Product Name: LED Street Light Power: 120W
    LEDs Qty.: 56 Pcs Input Voltage: 90-305V
    CCT: 143 Lm/W Light Size: 520x336x91 Mm
    Packing Size: 575x395x150 Mm Gross Weight: 5.08 Kg
    High Light:

    high lumen led street light

    ,

    led light street lamp

    U-SL1302-120W LED Street Light IP66 Led Street Light 120 Watt Led Street Light



    Description:

    LED street light is made of heavy-duty die-cast aluminum with integrated radiator and tempered glass lens. It is made of high-quality materials. The LED street lamp is manufactured in strict accordance with high standards to ensure safe and reliable use.​ Designed by a professional industrial design team, it can be applied to wind and solar hybrid street lighting systems with high-end, stylish and atmospheric appearance. Automatically judge the weather and reasonably plan the discharge power.



    The upgrade of urban lighting. Related plans and measures were issued in many places. The products are manufactured with high-quality materials and advanced technology. Upgrade road lighting to create distinctive night scene lighting. The aim is to improve the level of city management and build a smart city.



    Quick Detail:

    1. Using high-efficiency ZAG lens technology, compared with similar products, the light efficiency is increased by 8% and the light transmittance is as high as 98%.
    2. With air duct heat dissipation design, the overall weight of the product is reduced and the heat dissipation performance is good, reducing light decay and prolonging the life of the light source. The mainstream CHEM modular design reduces maintenance costs for later use.
    3. Low energy consumption, constant current drive, energy saving 60%; overcurrent, overvoltage, lightning, high temperature protection to fully guarantee the product's life and stability.
    4. Rugged and long-lasting, up to 50,000 hours; no need to change fixtures frequently, no routine maintenance required.
    5. Green and environmentally friendly, the light source is free of ultraviolet rays, infrared radiation, and no mercury pollution.
    6. Beautiful appearance without dust, protection class IP66.
    7. Fast response, no stroboscopic; wide operating voltage range.
    8. The lamp bead is housed in two 1W dual crystal packages and the dead light rate is reduced by an order of magnitude.
    9. Green and environmental protection, the light source has no ultraviolet, infrared radiation, and no mercury pollution.

    Distribution Curve:

    IP66 120 Watt Led Street Light Fittings , High Power Led Lamp U-SL1302-120W



    Product Details:

    Model U-SL1302-120W
    Power 120W
    Lumen efficacy 143 Lm/W
    Lumen flux 17160 lm
    CCT 5000-6000K
    CRI ≥70
    Brand of chips Bridgelux / San‘an
    LED Qty. 56 pcs
    Beam angle 150*45°/150*65°/150*70°
    IP level IP66
    Input voltage 90-305V
    Working temperature -40°C~50°C, 20%~90% H.R.
    Storage temperature -40°C~85°C, 10%~90% H.R.
    Power efficiency 90%
    PF >0.95
    Life span >50000H
    Pole diameter Φ60mm
    Housing material AL6063-T5
    Light size 520*336*91 mm (±5mm)
    Packing size 575*395*150 mm (±5mm)
    Light N. W. 5.08 kg (±0.1kg)



    Mechanical Drawing:

    IP66 120 Watt Led Street Light Fittings , High Power Led Lamp U-SL1302-120W



    Installation Diagram:



    1. Open the back board and back cover;
    2. Connect the light wires and grid wires;
    3. Insert the lamp pole into the light, lamp pole dia φ60mm;
    4. Make sure the light is steady, lock the push board M10 Hexagon socket head cap screws, fix the light tightly onto the pole arm;
    5. Close the back board, then back cover. Done;
    6. Connect light power supply wire and grid wire according to above picture, blue to N, brown to L, yellow&green to E.



    Applications:

    LED Street Light is widely used in urban expressways, highways, trunk roads, secondary roads, access roads, streets, factories, schools, gardens, parks, community, garden plaza and other street lighting.



    IP66 120 Watt Led Street Light Fittings , High Power Led Lamp U-SL1302-120W
