Low Frequency Power Solar Wind Inverter 12V-48V 260W-3500W Easy Maintenance

Low Frequency Power Solar Wind Inverter 12V-48V 260W-3500W Easy Maintenance

    • Low Frequency Power Solar Wind Inverter 12V-48V 260W-3500W Easy Maintenance
    • Low Frequency Power Solar Wind Inverter 12V-48V 260W-3500W Easy Maintenance
    • Low Frequency Power Solar Wind Inverter 12V-48V 260W-3500W Easy Maintenance
    • Low Frequency Power Solar Wind Inverter 12V-48V 260W-3500W Easy Maintenance
  • Low Frequency Power Solar Wind Inverter 12V-48V 260W-3500W Easy Maintenance

    Product Details:

    Place of Origin: China
    Brand Name: URILIC
    Certification: CE,UL,ISO9001
    Model Number: NPower Series NP-260-3500

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiable
    Price: Negotiable
    Packaging Details: Plywood
    Delivery Time: 7 working days after received payment
    Payment Terms: T/T
    Supply Ability: 1000 sets/ month
    Contact Now
    Detailed Product Description
    Product Name: Low Frequency Power Inverter Rated Power: 260W, 400W, 600W, 800W, 1KW, 1.2KW, 2KW, 2.5KW, 3KW, 3.5KW
    Battery Voltage: 12V, 24V, 48V AC Outpu: 220V/230V
    Output Frequency: 50HZ / 60HZ Application: Off Grid System, Charge Inverter
    Weight: 6~36.2kg Enclosure: IP20
    High Light:

    wind power inverter

    ,

    low frequency power inverter

    NPower 260W - 3500W Low Frequency Power Inverter Pure Sine Wave Inverter 12V - 48V

    Description:

    NPower series is a kind of pure sine wave inverter which can convert 12/24/48VDC to 220/230Vac.It is based on full digital and intelligent design, it adopts the advanced SPWM technology, voltage and current double closed-loop controlled and completely isolated inverter technology, such as to ensure the product with high quality electrical parameters, the stronger ability to resist impact load, the input surge prevention design at the same time.meet the special requirements of lithium battery surge limit, to ensure the safety and function of the inverter running and reliable. The case is designed with galvanized board,which has the advantages of high strength and corrosion resistance. This product has the characteristics of high reliability, high efficiency, simple appearance, complete protection function, easy installation and easy operation. It is suitable for AC load of household appliances,power tools, industrial equipment, electronic audio and video and solar photovoltaic power generation system, such as vehicle inverter application system, solar RV, solar household, solar yacht and solar power station.



    Low Frequency Power Inverter Features:

    • Adoption of advanced SPWM technology, pure sine wave output

    • Adopt voltage and current double closed-loop control to enhance the load capacity

    • The input and output adopt completely isolated inverter technology with high reliability

    • The input adopts anti-surge design to meet the special requirements of surge limitation of the lithium battery and avoid dangerous surge current generated by connection of startup.

    • Low output harmonic distortion(THD≤3%)

    • The output adopts excellent EMC design to prevent interference of connected equipment

    • Output voltage 220/230VAC and frequency 50/60Hz optional

    • Extensive protections: input reverse polarity, input overvoltage, input low voltage, output overload and short circuit, overheating.

    • RS485 port can connect the communication module, realize remote start/stop inverter and monitor the running status via the APP or PC software.

    • Set the input low voltage and low voltage reconnect voltage via the APP or PC software

    • Set the inverter’s ID via the APP or PC software to monitor several inverters.

    • The case is designed with the galvanized board, with high strength and strong corrosion resistance

    • Chinese dual socket, Australia/New Zealand, European, Terminal selectable

    • Easy maintenance and repair


    Product Details (NP-260, NP-400):

    Item NP-260-12 NP-260-22 NP-400-12 NP-400-22
    Output Continuous Power 260W@25℃;260W@45℃ 400W@25℃;350W@45℃
    Surge Power 400W 700W
    Output Voltage 220/230V
    (-8%~+3%)
    220/230V
    (±3%)
    220/230V
    (±3%)
    220/230V
    (±3%)
    Output Frequency 50/60±0.2%
    Output Wave Pure Sine Wave
    Output THD THD≤3%(Resistive load)
    Load Power Factor 0.2~1(VA≤Continuous output power)
    Rated input voltage 12V 24V 12V 24V
    Battery Input voltage range 10.8~16V 21.6~32V 10.8~16V 21.6~32V
    output efficiency of80%
    rated power①
    0.81 0.84 0.81 0.85
    Max. Rated Efficiency② 0.79 0.82 0.79 0.84
    Max. Efficiency③ 89%(80W) 90%(100W) 90%(100W) 91%(100W)
    No-load Current <0.4A <0.3A <0.5A <0.3A
    RS485 Com. Port 5DC/200mA
    Binding Post Φ6mm Φ6mm
    Overall dimension 365×212×97mm 386×215×99mm
    Mounting Dimension 220×193mm 230×196mm
    Mounting hole size Φ7mm Φ7mm
    Weight 6.34kg 6.24kg 6.24kg 7.86kg
    Working Temperature -20℃~+45℃(Full load)
    Storage Temperature -35℃~ +70℃
    Humidity < 95%(N.C.)
    Enclosure IP20
    Altitude < 5000 m (Derating to operate according to IEC62040 at a height exceeding 1000 m)


    Product Details (NP-600, NP-800, NP-1000):

    Item NP-600-12 NP-600-22 NP-800-12 NP-1000-22
    Output Continuous Power 600W@25℃; 500W@45℃ 800W@25℃;800W@45℃ 1000W@25℃;800W@45℃
    Surge Power 1000W 1600W 1600W
    Output Voltage 220/230V
    (-8%~+3%)
    220/230V
    (±3%)
    220/230V
    (-8%~+3%)
    220/230V
    (±3%)
    Output Frequency 50/60±0.2%
    Output Wave Pure Sine Wave
    Output THD THD≤3%(Resistive load)
    Load Power Factor 0.2~1(VA≤Continuous output power)
    Rated input voltage 12V 24V 12V 24V
    Battery Input voltage range 10.8~16V 21.6~32V 10.8~16V 21.6~32V
    output efficiency of80%
    rated power①
    0.81 0.85 0.83 0.85
    Max. Rated Efficiency② 0.8 0.83 0.81 0.82
    Max. Efficiency③ 89%(200W) 92%(160W) 92%(100W) 92%(200W)
    No-load Current <0.6A <0.4A <0.6A <0.4A
    RS485 Com. Port 5DC/200mA
    Binding Post Φ8mm 20*3mm(Rectangle) 20*3mm(Rectangle)
    Overall dimension 428×243×121mm 475×268×139mm 475×268×139mm
    Mounting Dimension 260×220mm 270×245mm 270×245mm
    Mounting hole size Φ9mm Φ9mm Φ9mm
    Weight 10.32kg 10.08kg 13.22kg 12.64kg
    Working Temperature -20℃~+45℃(Full load)
    Storage Temperature -35℃~ +70℃
    Humidity < 95%(N.C.)
    Enclosure IP20
    Altitude < 5000 m (Derating to operate according to IEC62040 at a height exceeding 1000 m)



    Product Details (NP-1200, NP-2000, NP2500):

    Item NP-1200-12 NP-1200-22 NP-2000-42 NP-2500-22
    Output Continuous Power 1200W@25℃;1000W@45℃ 2000W@25℃;
    2000W@45℃
    2500W@25℃;2500W@45℃
    Surge Power 2000W 4000W 5000W
    Output Voltage 220/230V
    (-8%~+3%)
    220/230V
    (±3%)

    220/230VAC

    (±3%)

    220/230VAC

    (-6%~+3%)

    Output Frequency 50/60±0.2%
    Output Wave Pure Sine Wave
    Output THD THD≤3%(Resistive load)
    Load Power Factor 0.2~1(VA≤Continuous output power)
    Rated input voltage 12V 24V 48VDC 24VDC
    Battery Input voltage range 10.8~16V 21.6~32V 43.2~64VDC 21.6~32VDC
    output efficiency of80%
    rated power①
    0.81 0.85 0.89 0.89
    Max. Rated Efficiency② 0.78 0.84 0.87 0.87
    Max. Efficiency③ 92%(200W) 93%(300W) 93%(500W) 93%(500W)
    No-load Current <0.6A <0.4A <0.3A <0.8A
    RS485 Com. Port 5DC/200mA 5VDC/200mA
    (Ioslation)
    5VDC/200mA
    Binding Post 20*3mm(Rectangle) M10
    Overall dimension 511×268×139mm 486×313×145mm 539×328×170mm
    Mounting Dimension 300×245mm 350×292mm 350×307mm
    Mounting hole size Φ9mm Φ9mm
    Weight 15.64kg 15.28kg 20.7kg 32.8kg
    Working Temperature -20℃~+45℃(Full load)
    Storage Temperature -35℃~ +70℃
    Humidity < 95%(N.C.)
    Enclosure IP20
    Altitude < 5000 m (Derating to operate according to IEC62040 at a height exceeding 1000 m)



    Product Details (NP-3000, NP-3500):

    Item NP-3000-22 NP-3000-42 NP-3500-42
    Output Continuous Power 3000W@25℃;3000W@45℃ 3500W@25℃;
    3500W@45℃
    Surge Power 6000W 7000W
    Output Voltage 220/230VAC(-5%~+3%) 220/230VAC(±3%) 220/230VAC(±3%)
    Output Frequency 50/60±0.2%
    Output Wave Pure Sine Wave
    Output THD THD≤3%(Resistive load)
    Load Power Factor 0.2~1(VA≤Continuous output power)
    Rated input voltage 24VDC 48VDC 48VDC
    Battery Input voltage range 21.6~32VDC 43.2~64VDC 43.2~64VDC
    output efficiency of80%
    rated power①
    0.88 0.9 0.9
    Max. Rated Efficiency② 0.86 0.89 0.89
    Max. Efficiency③ 94%(500W) 94%(900W) 93%(900W)
    No-load Current <0.8A <0.5A <0.5A
    RS485 Com. Port 5DC/200mA 5VDC/200mA(Ioslation)
    Binding Post M10
    Overall dimension 639×393×175.5mm 584×328×170mm 564×353×175mm
    Mounting Dimension 350×372mm 350×307mm 350×332mm
    Mounting hole size Φ9mm
    Weight 36.4kg 28.4kg 32.2kg
    Working Temperature -20℃~+45℃(Full load)
    Storage Temperature -35℃~ +70℃
    Humidity < 95%(N.C.)
    Enclosure IP20
    Altitude < 5000 m (Derating to operate according to IEC62040 at a height exceeding 1000 m)



    ①DC input voltage israted voltage, the load power is 80% of the continuous output power (25℃)
    ②DC input voltage israted voltage, the load power is as same as the continuous output power (25℃)
    ③DC input voltage israted voltage, max power with different load power.





    Application Topology:

    Low Frequency Power Solar Wind Inverter 12V-48V 260W-3500W Easy Maintenance
