| Place of Origin: | China |
| Brand Name: | URILIC |
| Certification: | CE,UL |
| Model Number: | 100Ah 48V |
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood box |
| Delivery Time: | 5-15 days |
| Payment Terms: | T/T |
| Supply Ability: | 1000PCS/month |
| Features: | High Energy Density | Product Name: | Off Grid Lithium Battery |
|---|---|---|---|
| Nominal Capacity: | 100Ah | Battery Voltage: | 48V |
| Size: | 629* 504.2*197mm | Weight: | 65kg |
| Type: | Lithium Battery | Application: | Solar Wind Hybrid System, Telecom |
| High Light: | off grid solar lithium battery,lifepo4 lithium battery |
||
100AH 48V Off Grid Lithium Battery Communication Base Station Power Supply
The 100AH 48V communication base station power supply industrial quality is base on advanced energy storage module based on LiFePO4 technology and intelligent management system. This realiable lithium battery is safe, durable and easy to install in any new or exsiting telecom sites; expecially suitable for off-grid sites.
The 100AH 48V communication base station power supply industrial quality is base on advanced energy storage module based on LiFePO4 technology and intelligent management system. This realiable lithium battery is safe, durable and easy to install in any new or exsiting telecom sites; expecially suitable for off-grid sites.
Quick Detail:
Product Details:
| Battery Pack | Nominal capacity | 100Ah |
| Nominal voltage | 51.2V | |
| Charge voltage | 56V-57.6V | |
| Maximum charging voltage | 58.4V | |
| Maximum charging current | 100A(1C3) | |
| Maximum discharge current | 100A(1C3) | |
| Standard charging current | 10A(0.1C3) | |
| Standard discharge current | 10A(0.1C3) | |
| Battery weight | ≤65Kg | |
| Maximum external dimensions (width*depth*thickness)(mm) |
629* 504.2*197 | |
| Proper temperature charging | 0℃～55℃ | |
| Proper temperature discharge | -10℃～65℃ | |
| Power Management System BMS | Single overvoltage protection value | 3.65V |
| Overpressure release value | 3.50V | |
| Single undervoltage protection value | 2.5V | |
| Undervoltage release value | 2.9V | |
| Overcurrent protection value | 120A | |
| Overcurrentshort circuit protection recovery condition | Charging release | |
| Balanced on | ≥3.5V,Pressure difference 30mV | |
| Letter of agreement | RS485,RS232 |
100AH 48V Communication Base Station Power Supply Dimensions
Design Features:
Higher Power: Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity.
Superior Safety: Lithium Iron Phosphate chemistry eleminates the risk of explosion or combustion due to high impact overcharging or short circuit situation.
Lighter Weight : About 40% of the weight of a comparable lead acid battery . A " drop in" replacement for lead acid batteries
Wider Temperature Range: -20℃~60℃
