| Place of Origin: | China |
| Brand Name: | URILIC |
| Certification: | IEC62619, UN38.3 |
| Model Number: | USES-B102V25Ah |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plywood box |
| Delivery Time: | 5-15 days |
| Payment Terms: | T/T |
| Supply Ability: | 1000PCS/month |
| Product Name: | Off Grid Lithium Battery | Nominal Voltage: | 102V |
|---|---|---|---|
| Nominal Capacity: | 25Ah | Norminal Energy: | 2.5KWh |
| Battery Module Size: | 440 X 86 X 550mm | Battery Module Weight: | 27kg |
| Control Box Size: | 440 X 86 X 550mm | Control Box Weight: | 10kg |
| High Light: | off grid solar lithium battery,lifepo4 lithium battery |
||
48V 50AH Off Grid Lithium Battery Power Supply Storage Energy System
High level performance requires high power input. USES-B10225 delivered with a CAN Bus equipped Control box, can provide over 1000V output.
Key Features:
Product Specifications:
| 2.5kWh battery module specification | ||
|
Packaging |
32S1P |
|
|
Voltage |
Nominal, 102.4V, Range: 86.4V~112V |
|
|
Capacity |
25Ah |
|
|
Max Current |
Discharge15 A |
Charge 12 A |
|
0~19 A |
0~16A |
|
|
Impedance |
＜100 mΩ (50%SOC, 25℃, 1kHz) |
|
|
Cycle life |
6000 times, Remaining 70% (0.5C charge and discharge; 80%DOD, 25℃) |
|
|
Communication |
CAN/RS485 |
|
|
Cooling concept |
Passive cooling by air |
|
|
Operating Temperature |
Charge |
0℃-55℃ |
|
Discharge |
-20℃-60℃ |
|
|
Storage Temperature* |
(-20℃-25℃) |
12 months |
|
(-20℃-45℃) |
3 months |
|
|
(-20℃-60℃) |
1 month |
|
|
Environment humidity |
operating |
10%-80% |
|
Storage |
10%-80% |
|
|
Certification |
IEC62619, UN38.3, RoHS |
|
|
Dimension(W * H * D) |
440 * 86 * 550mm |
|
|
Net Weight |
27kg |
|
|
Control box parameter |
||
|
Input voltage |
0V-1000V |
|
|
Max.Current |
30A |
|
|
Communication |
CAN/ RS485 |
|
|
Cooling concept |
Passive cooling by air |
|
|
Battery module connection type |
Connect in series, MAX.8 battery modules |
|
|
Operating temperature |
-20℃-60℃ |
|
|
Operating humidity |
10%-80% RH |
|
|
Certification |
IEC61000 |
|
|
Insulation resistance |
DC output to case 2MΩ, 1000VDC |
|
|
High-voltage insulation |
DC output to case 2000VAC, 10mA,10s |
|
|
Dimension(W * H * D) |
440 * 86 * 550 mm |
|
|
Net Weight |
10kg |
|
Applications:
Energy Storage: Solar Wind Hybrid Power System, City On Grid or Off Grid, Community and Family.
Back up System and UPS: Telcom Base, CATV system, Computer Server Center, Medical Instrumnt, Military Equipment .
Our advantage:
URILIC is the world's leading manufacturer and marketer of energy-supply systems, primarily for wind and light energy front-end power generation, back-end energy storage applications, and product range from intelligent integration of new energy peripheral products.
URILIC is constantly striving to become China's leading OEM/ODM manufacturer. To this end, URILIC is committed to working with world-class brands to deliver on our promises and provide partners with complete power solutions.
