| Place of Origin: | China |
| Brand Name: | URILIC |
| Certification: | Customized Product |
| Model Number: | Solar wind hybrid system square light pole |
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Multiple packaging |
| Delivery Time: | 10-30 work days |
| Payment Terms: | T/T |
| Supply Ability: | 1000 sets/ month |
| Product Name: | Tower Foundation Street Light Poles | Pole Material: | Hot Rolled Steel Q235 |
|---|---|---|---|
| Pole Height: | 3m-12m (Optional) | Pole Type: | Octagonal Pole, Conical Pole |
| Wind Speed: | 160 Km/Hour | Thickness: | 3-10mm |
| Color: | Green, Grey, Blue, Optional | Application: | Street Lighting, Monitoring System |
| High Light: | tower foundation,lamp post foundation |
||
Tower Foundation Street Light Poles Solar Wind Hybrid System Square Light Pole
Description:
There are two general types of light poles, round rods and vertebral rods. Round rods refer to the same diameter as the upper and lower rods. They are often used in situations where the height of the light rod is not high. In occasions, vertebral rods have better mechanical strength and wind resistance than round rods. Square poles are also often used to design special-shaped poles to meet users' special requirements for appearance.
The materials used for street lights are: Q235 high-quality steel, mainly divided into galvanized pipes and black pipes. Galvanized pipes are pipes made of galvanized sheet, but the rust resistance is worse than hot-dip galvanized. Tie steel plate.
Anti-rust treatment is generally: hot-dip galvanized and galvanized, sprayed anti-rust paint, or made of galvanized material, the best anti-rust ability is hot-dip galvanized, followed by galvanized material, sprayed zinc, sprayed paint.
Spraying powder: electrostatic spraying, plastic spraying for short, and spraying plastic spraying are divided into two types of materials: outdoor powder, indoor powder, outdoor powder can be anti-ultraviolet indoor powder is not anti-ultraviolet.
Customizable tower pole series products mainly include: electric steel poles, steel pile foundations, piling construction, street light poles, signal light poles, various red street light poles, highway and park lighting poles, and a complete set of series.
Mobile Communication Tower Pole Description:
|
Pole’s height |
3m to 15m |
|
Shape of pole |
Round conical; Octagonal tapered; Straight square; Tubular stepped; Shafts are made of steel sheet that folded into required shape and welded longitudinally by automaticarc welding machine |
|
Brackets/ Arm |
Single or double brackets/ arm are in the shape and dimension as per customers requirement |
|
Length |
Within 14m once forming without slip joint |
|
Thickness |
3mm to 20mm |
|
Welding |
Advanced submerge-arc welding and CNC welding equipment. It has past flaw testing, internal and external double welding makes the welding beautiful in shape. It confirms with the international welding standard. It has past flaw testing.Internal and external double welding makes the welding beautiful in shape. And confirms with international welding standard of CWB |
|
Jointing |
Jointing of pole with insert mode,innerflange mode,face to face joint mode. |
|
Base plate mounted |
Base plate is square or round in shape with slotted holes for anchor bolt and dimension as per customers requirement. |
|
Ground mounted |
The length buried underground as per customers requirement. |
|
Galvanizing |
Hot dip galvanization with thickness of 80-100µm average in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123, IS: 2626-1985. |
|
Powder coating |
Pure polyester powder painting, color is optional according to RAL Color stardand. |
|
Wind Resistance |
Aganist wind pressure of 160Km/h |
|
Manufacturing |
According to GB/T 1591-1994. |
|
Quality Control |
We control the quality according to the flow of ISO9001-2008. Quality is employed at every stage of production to ensure the product compliance to the specifications/standards. Careful inspections are carried out by highly trained inspection engineers as per the defined procedures from raw material stage to finished product and delivery. Prototype assembly of towers is carried out in the plant. |
|
Certificates |
ISO9001-2008 SGS Audited Supplier |
For Customization Please Contact Us
Name: Street Light Pole
Height: 3-14 meters (can be customized according to customer requirements)
Thickness: according to the specific height (can be customized according to customer requirements)
Color: blue-white (can be customized according to customer requirements)
Material: Q235 high quality steel
Process: hot-dip galvanizing + plastic spraying
Style: A-shaped arm, self-bending arm, conch arm, etc. (can be customized according to customer requirements)
Lighting: You can consult customer service if you need lighting accessories
Application: Suitable for urban roads, residential areas, tourist attractions, public places, etc.
