| Place of Origin: | SHENZHEN |
| Brand Name: | URILIC |
| Certification: | ETL, TUV, CE, RoHS |
| Model Number: | FLHB-V5M1-50W |
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Carton box |
| Delivery Time: | 5-15 days |
| Payment Terms: | T/T |
| Supply Ability: | 1000PCS/week |
| Wattage: | 50W | Products Name: | Outdoor LED Flood Lights |
|---|---|---|---|
| Light Size: | 330*80*265mm | Carton Size: | 385*250*362mm (2pc/carton) |
| Chip Brand: | Bridgelux | Net Weight: | 18.6kg,±0.1kg |
| Housing Material: | AL 6063-T5 | Lumen: | 7750 Lm |
| High Light: | led outside flood lights,smd flood light |
||
50W LED Flood Light FLHB-V5M1 Indoor LED High Bay Outdoor LED Flood Lights
Description:
Use cooling duct design, product overall weight reduction and thermal performance, reduce light decline, and prolong lamp’s lifetime. With popular CHEM modular design, can effectively reduce the maintenance costs later use. Low-energy, use high efficiency constant current driver, 60% energy-saving ; With over-current, over-voltage, lightning, high temperature protection to fully guarantee the lifespan and stable performance.
Use efficiency zero air gap lens technology, achieves zero light loss. It’s 8% higher efficiency than other similar products, and 8%, light transmission rate reaches 98%.
Product Details:
|
Model |
FLHB-V5M1-50W |
||
|
Power |
50W |
||
|
CCT |
3000K/4000K/5000K/6000K |
||
|
Beam angle |
25°/ 40°/ 60°/ 90° |
||
|
Chip brand |
Bridgelux |
||
|
Leds qty. |
30pcs |
||
|
CRI |
≥70 |
||
|
Efficiency |
155-160 lm/w |
||
|
Lumen |
7750 lm |
||
|
IP IK Rate |
IP66, IK10 |
||
|
Working voltage |
90-305V |
||
|
Working temperature |
-40℃~50℃, 20%~90% H.R |
||
|
Storage temperature |
-40℃~85℃, 10%~90% H.R. |
||
|
Power efficiency |
93% |
||
|
PF |
>0.98 |
||
|
Lifespan |
50000 Hours |
||
|
Housing material |
AL6063-T5 |
||
|
Light size |
330*80*265mm ±5mm |
||
| Carton size | 385*250*362mm ±5mm (2pcs/carton) | ||
|
N.W. |
3.25kg ±0.1kg |
Mechanical Drawing:
Distribution Curve:
25°,40°,60°,90°,145x100°,150° for option,Uniform light distribution apply to different industrial light project.
Outdoor LED Flood Lights Features:
Applications:
The 50W LED Flood Light FLHB-V5M1 Indoor LED High Bay Outdoor LED Flood Lights applied to workshop, industrial building, sports center, gas station, parking lots, waiting room, train station, harbor, wharf and other large energy-saving lighting. With building facade and public corridor, stair corridor, garden designs and some other indoor and outdoor places where need spot lighting and light decoration,etc
Maintenance:
